Colored highlighting replaces legacy dashed-style highlighting. The main elements of Quick Input are the tooltips near the cursor, which act as inputs for coordinates, distances, and angles. Quick Input provides a command entry interface near the cursor, so you can keep focus on geometry. Dimension widgets let you place dimensions automatically along Dimension Bounding Boxes (a) aligned with other dimensions, (b) spaced from the existing dimensions, and (c) spaced with the predefined offset distances.
You can adjust fade, contrast, and monochrome values. Adjusts the appearance of DGN Underlays against the graphics area background. You can control the text direction and location, and modify the text format and style. Explodes Blocks with BlockAttribute and keeps attribute value as text. More tools for Blocks and BlockAttributes.
#Draftsight 2018 update
Options to create, delete, append to, and update are available on editing contextual menu. Manually updates Dimension Bounding Boxes. Removes entities from an existing Dimension Bounding Box and changes the extents of the bounding box. Adds entities to an existing Dimension Bounding Box and changes the extents of the bounding box. Creates a dimension bounding box that encloses selected entities to align dimensions. Lets you align dimensions of objects located within a Dimension Bounding Box along the box margins at defined offsets to let them appear in a uniform arrangement. Dassault Systèmes ha annunciato il rilascio di DraftSight 2018 SP0, la prima release della nuova versione 2018 di DraftSight.Įcco le novità di questo rilascio (le funzionalità contrassegnate da un asterisco (*) sono quelle disponibili anche per la versione free):
